2012 Citzen A-32

OFFER FOR CITIZEN A32 LATHES  YOM 2012

- Number of axes : 5

- Number of spindles : 2

    MAIN SPINDLE

 -Max. bar diameter : 32 [mm]

- Max. machining length : 320 [mm]

- Travel : 325 [mm]

- Spindle speeds : 200 - 8.000 [rpm]

- Spindle power : 5,5 / 7,5 [kW]

- C axis indexing precision : 0,001 [°]

    GUIDE BUSH HOLDER 1

- Number of positions : 10

- Number of motorized positions : 4

- Live tools speed : 200 - 5.000 [rpm]

- X/Y stroke : 110 / 400 [mm]

  END ATTACHMENT

- Number of positions : 4

   SECONDARY OPERATION

- Number of positions : 5

- Number of motorized positions : 4

- Live tools speed : 200 - 5.000 [rpm]

  POWER SUPPLY

- Supply voltage : 400 [V]

- Total installed power : 15 [kVA]

  WEIGHT & DIMENSIONS

- Machine floor space : 2.520 x 1.300 [mm]

- Machine height : 2.229 [mm]

- Machine weight : 3.500 [kg]

  MACHINE HOURS

- Number of hours under power : 34.000
