2006 Brother TC-32B QT

2006 Brother TC-32B QT

Kontakta oss för pris

ellerRing 468-765 25 20

Beskrivning

5-Axis Vertical Machining centre  Brother

Year of Manufacture:L 2006

Control: Brother



MILLING SPINDLE

- Tool holder type : HSK40

- Spindle power : 7,3 [kW]

- Spindle speeds : 16.000 [rpm]

LINEAR AXES

- Travels on X/Y/Z axes : 550 x 400 x 415 [mm]

- Rapid traverses rates (X/Y/Z) : 70 [m/min]

- Cutting feed rates (X/Y/Z) : 1 - 20.000 [mm/min]

TOOL CHANGER

- Auto. Tool Changer type : Arm type

- Tool magazine capacity : 26

- Tool exchange time : 1,1 [sec]

PALLET CHANGER

- Pallet size : 600 x 425 [mm]

- Pallets number : 2

- Pallet exchange time : 3,4 [sec]

- Distance table / spindle nose (min./max.) : 230 - 645 [mm]

POWER SUPPLY

- Supply voltage : 380 [V]

- Total installed power : 37 [kVA]

WEIGHT & DIMENSIONS

- Machine floor space : 1.890 x 3.669 [mm]

- Machine height : 2.360 [mm]

- Machine weight : 4.500 [kg]


Specifikationer

TillverkareBrother
ModellTC-32B QT
År2006
SkickAnvänd
Lagernummer1148
