2017 Gehring Precision Honing Machine Model 630-1 LR

Machine Name:

Precision Honing Machine

Manufacturer:

Gehring

Model:

630-1 LR

Year of Manufacture:

2017

Precision Honing Machine - Gehring 630-1 LR

• Stroke length: 600 mm
• Honing diameter range: 3 – 45 mm
• Spindle drive: Servomotor
• RPM, max: 4500 1/min
• Torque: 60 Nm
• Stroke drive: Ball screw
• Stroke speed, max: 40 m/min
• Stroke acceleration, max: 25 m/s²

Gehring precision honing spindle:

• 3 stations: 1. Loading/Unloading -- 2. Honing -- 3. Measuring
• Gehring digital honing control, incl. fault diagnosis, with free programmable controller Siemens S7-300.
• Spindle feed EMZ-F
