2018 Hyundai Wia i-cut 380 MD

Make                                                                       Hyundai Wia

Model                                                                      i-Cut 380 MD

Year of manufacture                                            2018

Control system                                                      Siemens 828 chop-mill and 3D simulation

Pallets                                                                    650x400 mm

Pallet load                                                             250 kg

Traverses          X/Y/Z                                            560/360/480 mm

Rapid feed       X/Y/Z                                            50/50/56 m/min

Spindle speed                                                        24,000 rpm

Spindle power                                                       10.5/8 kW

Tool taper                                                               BT 30 Big plus

Number of tools in the magazine                     20 pcs.

Machine dimensions LxWxH                             2.0x2.7x2.85 m

Length: X-way                                                        2.0 m

Width incl. chip conveyor                                   4.1 m

Machine weight                                                    5200 kg

Equipment: Chip conveyor with drum filter, swivel, pallet changer, Fixture plate with reference holes.
